Carbon Road Frame model XB-R05 is our hottest item. The size is available for 49/52/54/56/59cm. Weight is about 1150+/-30g (54cm). UD, painting to order. 1-1/8" head tube. BB86 full carbon bottom bracket. 2 years warranty time.
overview
specs
customized
technology
X-BIKE products are race tested and put through the strictest quality control processes. All items have passed SGS, EN test.
Frame is the heart for carbon bicycle. Stiffer and faster, it is designed for racing amd handcrafted in OEM factory. Order a frame only - or let us build it up depending on your specs as Unparalleled bike in the world !
Subject : AERO Carbon Road Bicycle Frame
| Brand | X-Bike |
| Frame | XB-R05 (frame+fork+seat post+headset+seat post+handlebar+spacer) |
| Size | 49,52,54,56,59mm |
| Fork | FK05 Integrated |
| Seat Post | SP05 (L=380mm) |
| Handlebar | RH05 Integrated Stem Size: 90,100,110,120mm Handlebar Size: 400,420,440mm |
| Weave | UD matte/glossy |
| Finishied | To order |
| Type | Road Bikes Carbon Frame |
| Material | High Modulus Toray T700 Carbon Fiber |
| Clamp Type | Hidden clamp |
| Brake Type | Front and rear:SHI-MANO 9010/6180/5810 or TRP-731 |
| Weight | Frame 1150g(54mm), Fork 359g, Seat post 185g |
| Quick Release | Front 9*100 QR, Rear 9*130 QR |
| Head Tube | 1-1/8'' |
| Bottom Braket | BB86 full carbon |
| Tire Size | 700*25C |
| Warranty | 2 years |
| Test | SGS |
Customized frames per your specs depending on your base. Mould design is our greatest superiority.
TT frame, Track frame, Road frame, MTB (Hard Tail,XC , AM ,DH) frame, Fatbike frame and other bicycle parts (fork, handlebar, stem, saddle, seat post, bottle cage...) to your options.
Water-transfer decal, sticker and painting service for OEM your brands. You could tell us your unique design of decal, for example letters, outline, color, size and so on. Then our designer will make the impression drawing for you.
